DALI Track Lighting LED 30W 3 Phase CRI 92
DALI Track Light 30W 3 Phase CRI 92 features an aluminum body and CREE LED technology, delivering efficient illumination at 110LM/W. With SDCM 3 and CRI 92, it ensures accurate color rendering. The light is flicker-free and not a blue light hazard, offering enhanced visual comfort. Compatible with renowned DALI drivers like BOKE, Tridonic, Osram, VS, or TCI, it guarantees reliable performance. The track light is available with different lens options (15°, 25°, 36°, or 60°) for precise beam control. Designed for seamless integration, it works effortlessly with DALI Lighting Systems, making it an excellent choice for various commercial and architectural applications.
Highlights
→ DALI2
→ Aluminum Body
→ Lens 15°, 25°, 36°, or 60°
→ CREE COB CRI>92
→ 3 Phase
| Model | Wattage | Lumen Output | Dimensions |
| ILED-TL-D1 DALI | 10W | 1100LM (110LM / W) | D62xL170xH140mm |
| ILED-TL-D2 DALI | 15W | 1600LM (110LM / W) | D72xL185xH170mm |
| ILED-TL-D4 DALI | 30W | 3300LM (110LM / W) | D80xL185xH175mm |
| ILED-TL-D6 DALI | 40W | 4400LM (110LM / W) | D94xL190xH180mm |
| Input | 220-240VAC/110-277VAC | LED Source | Citizen or CREE COB |
| Materials | Aluminum+PC | PF | >0.9 |
| Watts | 10W/15W/30W/40W | Lumen Effective | 110LM/W |
| Lumen Output | 1100LM /1600LM/3300LM/4400LM | Adapt | 3 Phase 4 Wires for European
1 Phase 3 Wires for US
|
| Color Temperature | 2200-6000K | CRI | >92 , 95 or >97 |
| Electrical Classification | Class I | IP Rating | IP42 |
| Beam Angel | 12°,24°,36°or 60° | Body Color | White/Black |
| Warranty | 3-5 years | Certifications | SAA CE ROHS |
Send Your Inquiry
1. High Color Rendering Index (CRI): With a CRI of 92, this track light provides accurate and vibrant color representation, ensuring that objects and spaces are illuminated with exceptional color fidelity.
2. Versatility: The track light offers adjustable beam angles of 15°, 25°, 36°, or 60°, allowing for precise lighting distribution and flexibility in achieving desired lighting effects.
3. Energy Efficiency: With an impressive lumen efficacy of up to 110LM/W, the track light delivers efficient brightness while consuming only 15W of power, resulting in energy savings and cost-effectiveness.
4. Flicker-Free Operation: The built-in quality brand DALI driver, along with a power factor greater than 0.9, ensures stable and flicker-free lighting, promoting visual comfort and reducing eye strain.
5. Durability and Quality: The track light features an aluminum body, which provides durability and longevity. The CREE COB LEDs with LM80 certification ensure reliable performance and maintenance-free operation.
6. Seamless Integration: Equipped with a branded DALI driver from respected manufacturers like BOKE, VS, TCI, Osram, or Tridonic, the track light effortlessly integrates with DALI Lighting Control Systems, offering convenient and centralized control options.
7. Design and Aesthetics: The track light’s sleek design and powder-coated finish in black or white make it visually appealing and suitable for various architectural and interior design styles.
8. Multiple Installation Options: The track light can be installed on track rails, recessed mounting, or surface-mounted, providing flexibility to adapt to different installation requirements.
9. Long Lifespan: With a lifespan of 50,000 hours, the track light ensures long-lasting performance, reducing the need for frequent replacements and maintenance.
10. Suitable for Various Applications: Whether it’s commercial spaces, museums, residential areas, showrooms, or hospitality settings, the DALI Track Light excels in providing customizable and high-quality lighting solutions tailored to specific needs.
Q1: What is the power consumption of the DALI Track Lighting LED 30W 3 Phase CRI 92?
A1: The power consumption of this track light is 30 watts.
Q2: Can I adjust the color temperature of the track light?
A2: Yes, you can select the desired color temperature from options including 3KK, 4KK, 5KK, or 6KK.
Q3: What is the lifespan of the DALI Track Lighting LED 30W 3 Phase CRI 92?
A3: The track light has a lifespan of 50,000 hours, ensuring long-lasting performance and reducing the need for frequent replacements.
Q4: Does the track light come with a built-in driver?
A4: NO, the track light use an integrated DALI Driver and DALI Adapter, they are a quality brand DALI driver, such as BOKE, VS, TCI, Osram, or Tridonic, providing reliable and efficient operation without the need for additional drivers.
Q5: Can I adjust the beam angle of the track light?
A5: Yes, the track light offers beam angle options of 15°, 25°, 36°, or 60°, allowing for precise lighting control and customization.
Q6: Is the DALI Track Lighting LED 30W 3 Phase CRI 92 compatible with DALI Lighting Control Systems?
A6: Yes, this track light is designed to work well with DALI Lighting Control Systems, enabling centralized control, automation, and enhanced energy management capabilities.
1. Commercial Spaces: Install it in retail stores, showrooms, restaurants, offices, or hotels to create an inviting and vibrant atmosphere. The adjustable beam angles and high color rendering index ensure optimal lighting for showcasing products or creating a pleasant ambiance.
2. Art Galleries and Museums: The precise lighting control and accurate color representation of the track light make it ideal for illuminating artwork and exhibits. Its flicker-free operation ensures a comfortable viewing experience for visitors.
3. Residential Spaces: Use the track light in homes for accent lighting, highlighting artwork, architectural features, or specific areas. The soft and spot lighting options, along with its adjustable beam angles, allow for customized lighting effects in living rooms, bedrooms, or kitchens.
4. Showrooms and Exhibitions: Enhance the visual appeal of merchandise, cars, or other showcased products in showrooms or exhibitions. The track light’s high lumen efficacy and flicker-free performance ensure optimal visibility and attention to detail.
5. Hospitality Settings: Illuminate hotel lobbies, corridors, or reception areas with the DALI Track Light. Its sleek design, adjustable beam angles, and color temperature options can create a welcoming and luxurious atmosphere.
6. Galleries and Retail Spaces: Display products, merchandise, or artwork with precision and clarity. The high color rendering index and adjustable beam angles allow for optimal showcasing and visual impact.
DALI Track Light
1. Can the DALI adapter of this DALI Track Lights work with Global DALI Track Rail?
Yes, it is compatible.
2. Can you do the Color temperature as 2200K?
Yes, we can custom it as 2200K
| Model | Wattage | Lumen Output | Dimensions |
| ILED-TL-D1 DALI | 10W | 1100LM (110LM / W) | D62xL170xH140mm |
| ILED-TL-D2 DALI | 15W | 1600LM (110LM / W) | D72xL185xH170mm |
| ILED-TL-D4 DALI | 30W | 3300LM (110LM / W) | D80xL185xH175mm |
| ILED-TL-D6 DALI | 40W | 4400LM (110LM / W) | D94xL190xH180mm |
| Input | 220-240VAC/110-277VAC | LED Source | Citizen or CREE COB |
| Materials | Aluminum+PC | PF | >0.9 |
| Watts | 10W/15W/30W/40W | Lumen Effective | 110LM/W |
| Lumen Output | 1100LM /1600LM/3300LM/4400LM | Adapt | 3 Phase 4 Wires for European
1 Phase 3 Wires for US
|
| Color Temperature | 2200-6000K | CRI | >92 , 95 or >97 |
| Electrical Classification | Class I | IP Rating | IP42 |
| Beam Angel | 12°,24°,36°or 60° | Body Color | White/Black |
| Warranty | 3-5 years | Certifications | SAA CE ROHS |
Send Your Inquiry
1. High Color Rendering Index (CRI): With a CRI of 92, this track light provides accurate and vibrant color representation, ensuring that objects and spaces are illuminated with exceptional color fidelity.
2. Versatility: The track light offers adjustable beam angles of 15°, 25°, 36°, or 60°, allowing for precise lighting distribution and flexibility in achieving desired lighting effects.
3. Energy Efficiency: With an impressive lumen efficacy of up to 110LM/W, the track light delivers efficient brightness while consuming only 15W of power, resulting in energy savings and cost-effectiveness.
4. Flicker-Free Operation: The built-in quality brand DALI driver, along with a power factor greater than 0.9, ensures stable and flicker-free lighting, promoting visual comfort and reducing eye strain.
5. Durability and Quality: The track light features an aluminum body, which provides durability and longevity. The CREE COB LEDs with LM80 certification ensure reliable performance and maintenance-free operation.
6. Seamless Integration: Equipped with a branded DALI driver from respected manufacturers like BOKE, VS, TCI, Osram, or Tridonic, the track light effortlessly integrates with DALI Lighting Control Systems, offering convenient and centralized control options.
7. Design and Aesthetics: The track light’s sleek design and powder-coated finish in black or white make it visually appealing and suitable for various architectural and interior design styles.
8. Multiple Installation Options: The track light can be installed on track rails, recessed mounting, or surface-mounted, providing flexibility to adapt to different installation requirements.
9. Long Lifespan: With a lifespan of 50,000 hours, the track light ensures long-lasting performance, reducing the need for frequent replacements and maintenance.
10. Suitable for Various Applications: Whether it’s commercial spaces, museums, residential areas, showrooms, or hospitality settings, the DALI Track Light excels in providing customizable and high-quality lighting solutions tailored to specific needs.
Q1: What is the power consumption of the DALI Track Lighting LED 30W 3 Phase CRI 92?
A1: The power consumption of this track light is 30 watts.
Q2: Can I adjust the color temperature of the track light?
A2: Yes, you can select the desired color temperature from options including 3KK, 4KK, 5KK, or 6KK.
Q3: What is the lifespan of the DALI Track Lighting LED 30W 3 Phase CRI 92?
A3: The track light has a lifespan of 50,000 hours, ensuring long-lasting performance and reducing the need for frequent replacements.
Q4: Does the track light come with a built-in driver?
A4: NO, the track light use an integrated DALI Driver and DALI Adapter, they are a quality brand DALI driver, such as BOKE, VS, TCI, Osram, or Tridonic, providing reliable and efficient operation without the need for additional drivers.
Q5: Can I adjust the beam angle of the track light?
A5: Yes, the track light offers beam angle options of 15°, 25°, 36°, or 60°, allowing for precise lighting control and customization.
Q6: Is the DALI Track Lighting LED 30W 3 Phase CRI 92 compatible with DALI Lighting Control Systems?
A6: Yes, this track light is designed to work well with DALI Lighting Control Systems, enabling centralized control, automation, and enhanced energy management capabilities.
1. Commercial Spaces: Install it in retail stores, showrooms, restaurants, offices, or hotels to create an inviting and vibrant atmosphere. The adjustable beam angles and high color rendering index ensure optimal lighting for showcasing products or creating a pleasant ambiance.
2. Art Galleries and Museums: The precise lighting control and accurate color representation of the track light make it ideal for illuminating artwork and exhibits. Its flicker-free operation ensures a comfortable viewing experience for visitors.
3. Residential Spaces: Use the track light in homes for accent lighting, highlighting artwork, architectural features, or specific areas. The soft and spot lighting options, along with its adjustable beam angles, allow for customized lighting effects in living rooms, bedrooms, or kitchens.
4. Showrooms and Exhibitions: Enhance the visual appeal of merchandise, cars, or other showcased products in showrooms or exhibitions. The track light’s high lumen efficacy and flicker-free performance ensure optimal visibility and attention to detail.
5. Hospitality Settings: Illuminate hotel lobbies, corridors, or reception areas with the DALI Track Light. Its sleek design, adjustable beam angles, and color temperature options can create a welcoming and luxurious atmosphere.
6. Galleries and Retail Spaces: Display products, merchandise, or artwork with precision and clarity. The high color rendering index and adjustable beam angles allow for optimal showcasing and visual impact.
DALI Track Light
1. Can the DALI adapter of this DALI Track Lights work with Global DALI Track Rail?
Yes, it is compatible.
2. Can you do the Color temperature as 2200K?
Yes, we can custom it as 2200K
